Process Pipework Systems

Charles Thompson’s packaged process piping systems division offers a service tailored to suit your – often unique – requirements, from the manufacture of individual pipe spools to fully engineered and constructed piping systems.

Process piping system projects are allocated a Charles Thompson project manager to oversee all aspects of the job from design to delivery and final inspection, ensuring milestones, deadlines, quality and safety specifications and budgets are met.

Process Piping Systems Design Services

From the submission of your initial P&IDs and project specification, Charles Thompson will develop the piping system layout and complete the detailed package engineering activities, including the mechanical design of piping and supporting structures and the production of associated detailed fabrication drawings.

Charles Thompson’s in-house mechanical design services are complemented by our electrical and instrument design services, which offer clients a comprehensive range of project options including:

  • The specification and procurement of electrical equipment
  • Instruments and controls
  • The installation of this equipment

The final completed piping system can be functionally tested at Charles Thompson's works prior to dispatch.

Process piping systems can be provided in Carbon Steels, Stainless Steels, Duplex and Super Duplex steels, Nickel Alloys, Titanium, Zirconium and clad combinations.

We have a unique knowledge of high pressure API rated piping systems suitable for high level H2S sour service applications, where remote operation is required.

Charles Thompson’s packaged process piping systems division will also refurbish plants on site.
